Description

Product Description

Legrand 660-BKG is a Trademaster self-grounding single-pole toggle switch rated 15 A at 120 VAC and 1/2 hp motor load. It is constructed of high-impact thermoplastic with a satin finish and is designed for mounting in a standard wall box for indoor dry locations. The device supports back-and-side wiring with push-wire termination and accepts #14–#10 AWG solid and stranded conductors.

  • Electrical rating: 15 A at 120 VAC; 1/2 hp motor rating
  • Wiring: back and side terminations with push-wire option; accepts #14–#10 AWG
  • Construction: high-impact thermoplastic, satin finish; extra-long strap; mounts in standard wall box

Product Highlights

Self-grounding single-pole toggle switch for indoor dry wall-box installations with push-wire and side-wire termination.

Product Information

Standard Information

  • Brand: LEGRAND
  • Manufacturer Part Number: 660-BKG
  • Country of Origin: Vietnam
Technical Specifications
Brand
Legrand
MPN
660-BKG
Model
660BKG
Product Type
Self-grounding toggle switch
Product Family
Trademaster
Number of Poles
1
Switch Type
Toggle
Input Voltage
120 VAC
Current Rating
15 A
Horsepower Rating
1/2 hp
Load Rating
15 A @ 120 VAC
Load Type
CFL, Fluorescent, Halogen, Incandescent, LED, Universal, Xenon
Material
High-impact injection molded thermoplastic
Finish
Satin
Connection Type
Back and side; push-wire option
Wire Gauge
#14 AWG - #10 AWG (solid and stranded); copper-clad aluminum and copper supported
Mounting Type
Wall box
Location Rating
Indoor / Dry
Number of Gangs
1
Throw Type
Single throw
Terminal Accommodation
#14 AWG - #10 AWG
Dimensions (H x W x D)
4.195 in x 1.25 in x 1.09 in
Country of Origin
Vietnam
Standards / Certifications
UL 498; cULus listed; CSA listed (File 140597)
UPC
785008000000
