Legends 101-421NL 4 T-2000 No Lead Ball Valve

Product Description

The Legend Valve 101-421NL is a four-inch T-2000 no lead ball valve. It features a FNPT end style and operates at a pressure rating of 400 psi CWP. This valve is suitable for natural, manufactured, and mixed LP gas or air mixtures. It is equipped with a lever-operated actuator and a stainless steel ball. The valve has a length of seven point five four inches from inlet to outlet and measures five point nine three inches from top to inlet center. The body and stem are made of forged brass, while the seat trim is PTFE. The softgoods are constructed from PTFE and EPDM rubber.

• Lead-free design compliant with no-lead potable water laws
• Dezincification-resistant forged brass
• Self-cleaning chrome plated ball

Product Highlights

This valve is designed for durability and reliability in varying water conditions. The design ensures strong sealing properties.

Product Information

Standard Information

• Manufacturer: Legend Valve
• MPN: 101-421NL

Technical Specifications

• Actuator Type: Lever Operated
• Ball Material: Stainless Steel
• Body Material: Forged Brass
• Pressure Rating: 400 psi CWP
• Nominal Size: 4 in
• Inlet to Outlet Length: 7.54 in
• Top to Inlet Center: 5.93 in
• Softgoods Material: PTFE/EPDM Rubber
