Legend Valve LEG450-868P 2 inches No Lead Press x Pex F1960 Adapter

Product Description

The LEGEND VALVE LEG450-868P is a no lead press x PEX F1960 adapter that adapts a line from copper press to PEX piping. Press-type end connections eliminate soldering, reducing labor and material costs and eliminating the fire hazard. It is NSF certified to NSF/ANSI Standard 61, including NSF/ANSI 372.

• No lead DZR forged brass PEX (F1960) adapter
• Adapts a line from copper press to PEX piping
• NSF certified to NSF/ANSI Standard 61, including NSF/ANSI 372

Product Highlights

The LegendPress adapter features press-to-connect connections designed for installation onto ASTM B88 types K, L and M hard-drawn copper tubing. It has molded recess O-rings which create leak-path at multiple points during the pressure test to identify an un-pressed joint quickly.

Product Information

Standard Information

• Brand: LEGEND VALVE
• Manufacturer Part Number: LEG450-868P

Technical Specifications

• Size: 2"
• Configuration: Press x PEX (F1960)
• Additional Information: Lead-Free
• Connection Size 1: 2 in
• Connection Size 2: 2 in
• Connection Type 1: Press
• Connection Type 2: F1960 PEX
• Fitting Type: Adapter
• Material Construction: Brass
• Pressure Rating: 200 psi
• Temperature Rating: 0 to 250 deg F
