Legend Valve 104-303 T-401 Gate Valve 1/2 in

Product Description

The Legend Valve 104-303 T-401 gate valve features a 1/2 in nominal size and FNPT end style. Constructed with a cast brass body and brass trim, it is suitable for residential or commercial potable water applications. The handwheel actuator allows for manual operation.

• Durable, all-brass body construction and heavy cast iron hand wheel
• Electric-induction furnace casting process optimizes molten brass temperatures, resulting in superior cast body and bonnet components
• Inserted bonnet with large stem packing and forged packing-nut

Product Highlights

This Legend Valve gate valve is designed for reliable performance in potable water systems, featuring a non-rising stem and solid wedge disc.

Product Information

Standard Information

• Brand: Legend Valve
• Manufacturer Part Number: 104-303
• Country of Origin: Taiwan, Province of China

Technical Specifications

• Actuator Type: Handwheel
• Body Material: Cast Brass
• End Style: FNPT
• Hand Wheel Diameter: 2.13 in
• Inlet to Outlet Length: 1.69 in
• Nominal Size: 1/2 in
• Pressure Rating: 200 psi CWP
• Series: T-401
• Softgoods Material: NBR Stem Packing
• Temperature Rating: 200 deg F
• Top to Inlet Center: 2.84 in
• Trim Material: Brass
• Size: 1/2"
• Pipe Size: 1/2"
• Standards: 200 CWP
• Connection Type: FNPT x FNPT
• Brand: Legend Valve
• Model Number: T-401
• Manufacturer: Legend Valve
• Item Type Name: Brass Gate Valves
• Included Components: Valve
• MFR #: 104-303
