Leeson 113649.00 AC Motor 1/4 hp 1725 rpm Three Phase 208-230/460

Product Description

The Leeson 113649.00 is an AC motor designed for general purpose applications. This motor offers a power output of one-quarter horsepower and operates at a speed of 1725 rpm. It is suitable for three-phase operations and supports a voltage rating of 208-230 or 460 volts. The motor features a totally enclosed non-ventilated (TENV) design, making it reliable for various environments.

• Power Output: 1/4 hp
• Speed: 1725 rpm
• Voltage: 208-230/460 volts

Product Highlights

This motor is designed for efficient usage and durability. It has a round mounting feature and is reversible, allowing flexible installation. The frame is a 56C type, constructed from rolled steel for strength.

Product Information

Standard Information

• Weight: 22.0 LB
• Application: General Purpose

Technical Specifications

• Frame Material: Rolled Steel
• Phase: Three Phase
• Full Load Amps: 1.1/0.55
• Enclosure: TENV
• Service Factor: 1.15
• Hz: 60
• Voltage Rating: 208-230/460
• Rotation: Reversible
