Leeson 102863.00 AC Motor 0.33 hp 1725 rpm Three Phase 208-230/460

Product Description

The Leeson 102863.00 AC Motor is a general purpose motor designed for a variety of applications. With a power rating of 0.33 horsepower and a speed of 1725 rpm, this motor operates efficiently in a three-phase system. It is suitable for voltages of 208-230/460 and features a totally enclosed non-ventilated design, making it ideal for environments where dust and moisture are present.

• 0.33 hp, 1725 rpm, three-phase motor
• 208-230/460 voltage rating
• Totally enclosed non-ventilated (TENV) enclosure

Product Highlights

This motor has a round mount design, is easy to install, and offers a service factor of 1.15. It is constructed with rolled steel for durability and features a reversible rotation capability.

Product Information

Standard Information

• Brand: Leeson
• Part Number: 102863.00

Technical Specifications

• Frame: S56C
• Mounting: Round
• RPM: 1725 rpm
• Enclosure Designation: Totally Enclosed Non Ventilated
• Motor Application: General Purpose
• Efficiency Group: 77%
• Frame Material: Rolled Steel
• Poles: 4
• Phase: Three Phase
• Voltage Rating: 208-230/460
• Hz: 60
• Full Load Amps: 1.3/0.65
• Service Factor: 1.15
• Insulation: B
• Weight: 19.0 lb
