Kipp K0122.1061 Adjustable Clamping Handle M6x1.00

Product Description

The KIPP K0122.1061 is an adjustable clamping handle with a threaded hole mount, designed for use on machine tools, fixtures, jigs, and industrial equipment where frequent manual adjustment is required. The handle features an M6 x 1.00 thread and a 40 mm handle length, giving operators a firm, controlled grip during clamping operations. The body is die cast zinc with a black powder-coated handle arm finish and a black oxide coating on the steel components, providing corrosion resistance and a clean professional appearance. This part is typically installed by machinists, tool and die technicians, and maintenance mechanics working with precision equipment assemblies.

The K0122.1061 suits light-duty clamping applications in industrial and manufacturing environments where a compact, low-profile handle is needed. With a 13 mm hub diameter, 9 mm threaded engagement depth, and a 20-degree handle arm angle, it fits into tight clearances while maintaining reliable clamping force. The modern-style handle arm offers an ergonomic alternative to fixed wing knobs or standard bar handles in applications requiring repeated repositioning.

Key Features

• M6 x 1.00 threaded hole mount with 9 mm thread engagement depth
• 40 mm handle radius length for comfortable manual torque application
• Die cast zinc body with 13 mm hub diameter and 13 mm hub depth
• Steel components with black oxide finish; handle arm powder coated black
• 20-degree handle arm angle for clearance in compact assemblies
• Compliant with DIN EN 12844, REACH, and RoHS standards

Compatibility

Designed as a direct-mount adjustable clamping handle for equipment and fixtures using an M6 x 1.00 threaded stud or boss, consistent with KIPP K0122 series hardware standards.

Installation Notes

Installation requires no special tools beyond a standard hex key or wrench to secure the threaded stud on the receiving component. Ensure the mating thread is clean and free of debris before engagement to protect the zinc body from cross-threading damage. Do not exceed hand-tight torque levels typical for M6 zinc hardware, as over-tightening can crack the die cast body. Thread engagement should meet the 9 mm minimum depth for reliable clamping performance.
