Kipp K0122.1041 Adjustable Clamping Handle M4 X 0.70

Product Description

The KIPP K0122.1041 is an adjustable clamping handle designed for tool-free manual fastening and positioning applications in industrial and mechanical assemblies. Built from die cast zinc with a powder-coated black finish, the handle provides a secure, ergonomic grip while resisting corrosion and wear. The M4 x 0.70 threaded hole connection engages through a 13 mm hub diameter and a 9 mm threaded length, making it well suited for light-duty clamping, fixture adjustment, and equipment alignment tasks. The 40 mm handle radius length and 20-degree arm angle deliver comfortable leverage for repeated tightening and release cycles. Licensed technicians, machinists, and maintenance professionals install this type of handle on jigs, fixtures, and machine guards.

This adjustable clamping handle fits installations where a compact, low-profile threaded fastening point is required. The 13 mm hub diameter and 10 mm base diameter keep the footprint small, suitable for tight panel layouts, enclosure latching, and workholding fixtures in both light manufacturing and maintenance environments. The steel components with black oxide finish complement the die cast zinc handle body, providing a two-material construction that balances weight and strength. At 0.07 pounds, the handle adds minimal mass to assemblies where weight management is a consideration.

Key Features

• M4 x 0.70 threaded hole connection with 9 mm threaded depth and 9 mm hole depth for positive thread engagement
• Die cast zinc handle body with powder-coated black finish for durability and corrosion resistance
• Steel components with black oxide finish complement the zinc handle construction
• 20-degree handle arm angle improves ergonomic leverage in confined mounting locations
• Compact 13 mm hub diameter and 10 mm base diameter suit tight-clearance assemblies
• Compliant with DIN EN 12844, REACH, and RoHS standards

Compatibility

Designed as an OEM-style replacement or direct-fit component for industrial fixtures, jigs, machine guards, and enclosures requiring an M4 x 0.70 threaded hole adjustable clamping handle with a 13 mm hub diameter.

Installation Notes

Installation is typically performed by machinists, maintenance technicians, or industrial assembly personnel using standard hand tools. Ensure the mating threaded stud or bolt meets M4 x 0.70 thread specifications before installation. Power down or de-energize any associated equipment before accessing panels or fixtures where this handle is being mounted. Do not exceed the handle design load for the M4 thread size, and verify thread engagement depth meets the 9 mm minimum for secure clamping.
