King Innovation 90220 3-Port Split-Bolt Utility Line Direct Bury 50V (5 Units)

Product Description

The King Innovation 90220 Split-Bolt Utility Line Direct Bury has 3 ports rated at 50 volts. Designed for low voltage tracer splices, it provides a secure connection without cutting the main line. It is waterproof and corrosion proof and installs in under a minute.

• Waterproof and Corrosion proof
• Pre-filled with dielectric silicone sealant
• Installs in one minute or less

Product Highlights

Approved for direct bury, this lug is designed for use with solid tracer and cathodic wires.

Product Information

Standard Information

• Brand: KING INNOVATION
• Manufacturer Part Number: 90220
• Country of Origin: US

Technical Specifications

• UPC: 719362902203
• Type: Direct Burial Splice Kits
• Depth: 1.93 Inches
• Width: 1.617 Inches
• Finish: Silicone
• Height: 1.14 Inches
• Material: Plastic
• Color Code: Light Blue
• Connection: Screw terminal
• Voltage Rating: 50 VAC
• Conductor Range: 14 AWG to 10 AWG
• Country of Origin: US
• Temperature Rating: -45 F to 400 F
• Number Of Conductors: 2
• Environmental Conditions: Wet/Dry Location
• Max Voltage: 50 V
• Wire Size Range: 14-10 AWG
• Sealant Type: Silicone
• Color: Blue
• Direct Burial: Yes
• Special Properties: Corrosion Resistant, Water Resistant
• Package Type: Bag
