Kennametal 5665795 Indexable Copy Face Mill 2 Inch

Product Description

The KENNAMETAL 5665795 is an indexable copy face mill designed for precision contouring and face milling operations on machining centers. Built around the 7792 series platform, this cutter accepts six XD 09 inserts and provides a maximum depth of cut of 0.059 inches. Through-coolant capability delivers cutting fluid directly to the insert edge, extending tool life and improving chip evacuation in demanding applications. The 0.75-inch arbor hole diameter provides secure spindle registration. This tool is installed and operated by machinists, tooling engineers, and CNC setup technicians in production and job-shop environments.

This face mill suits a wide range of copy milling and profiling applications in ferrous and non-ferrous materials. With a 2-inch cutting diameter and a 1.574-inch overall height, it fits standard vertical and horizontal machining center spindles equipped with a compatible 0.75-inch arbor. The six-insert configuration balances cutting forces evenly, making it appropriate for both roughing passes at shallow depths and finish-profile work where surface consistency is required.

Key Features

• Accepts six XD 09 indexable inserts for distributed cutting load
• Through-coolant design directs fluid to the cutting zone for improved tool life and chip removal
• 2-inch cutting diameter with 0.75-inch arbor hole for standard machining center fitment
• Maximum depth of cut of 0.059 inches suited to contouring and copy milling passes
• 1.574-inch overall height for compact tooling stack in tight-clearance setups
• 7792 series platform for consistent insert indexing and repeatability

Compatibility

Designed as an OEM-style replacement and standard production copy face mill compatible with machining center spindles accepting a 0.75-inch arbor and using XD 09 series indexable inserts. Cutter style designation is C7792VXD09-A2.00Z06R.

Installation Notes

Installation should be performed by a qualified machinist or tooling technician. Power down and lock out the machining center spindle before mounting or indexing inserts. Use the appropriate insert torque wrench specified by KENNAMETAL for XD 09 insert screws — do not substitute standard hex drivers, as under- or over-torquing will affect insert seating and cutter balance. Verify coolant port alignment with the spindle through-coolant supply before initiating a cutting cycle.
