Kennametal 2963632 Spotting Drill 10mm 118 Solid Carbide

Product Description

The KENNAMETAL 2963632 is a solid carbide spotting drill designed to create accurate center points and chamfered starter holes before follow-on drilling operations. Built to Series B511 standards, this single-ended tool features a 118-degree point angle, a 10 mm cutting diameter, and a TiAlN coating that extends tool life in demanding machining environments. The 38 mm overall length and compact 11.3 mm flute length make it well suited for CNC machining centers and manual mills where clearance and rigidity are priorities. It is installed and operated by machinists and toolroom professionals working in production or job-shop settings.

This spotting drill is used in general-purpose metal removal applications where precise hole location is critical before drilling, countersinking, or reaming. The right-hand spiral flute geometry promotes clean chip evacuation and consistent entry geometry. The straight-cylindrical shank seats directly in standard collets, drill chucks, or hydraulic tool holders with a 10 mm bore. Typical materials include steel, cast iron, aluminum, and other common structural metals found in general manufacturing workflows.

Key Features

• 118-degree point angle provides a standard spotting geometry compatible with most twist drill follow-on operations
• Solid carbide construction delivers higher rigidity and wear resistance compared to high-speed steel alternatives
• TiAlN coating improves heat resistance and extends tool life at elevated cutting speeds
• Right-hand cut with two spiral flutes for efficient chip removal during spotting
• Straight-cylindrical shank fits standard 10 mm collets and drill chucks without adapters
• Compact 38 mm OAL suits short-reach applications and close-tolerance fixturing

Compatibility

Designed as a general-purpose spotting drill for use in CNC machining centers, knee mills, and drill presses equipped with standard 10 mm straight-shank toolholding systems.

Installation Notes

Installation and operation should be performed by qualified machinists familiar with rotating cutting tool safety practices. Ensure the machine spindle is fully stopped and locked out before loading or removing the tool from the holder. Confirm the shank is fully seated and the collet nut or chuck is torqued to the toolholder manufacturer specification before commencing a cut. Follow applicable shop safety standards and machine tool manufacturer guidelines for speeds and feeds.
