Kennametal 1803175 Square-shoulder Face Mill 2 in 3 Insert

Product Description

The KENNAMETAL 1803175 is an indexable square-shoulder face mill designed for precision milling operations in metalworking and machining environments. Built around the Fix-Perfect series platform, this cutter accepts three BGHX 15L5 style inserts held in place by clamp and screw methods. It features a 0/90 degree lead angle and a 24-degree positive rake angle, producing clean, square shoulder profiles in a right-hand cutting direction. Through-coolant capability keeps the cutting zone cool and helps evacuate chips during continuous or interrupted cuts. This tool is installed and operated by machinists and tool-and-die professionals working on CNC milling centers and manual knee mills.

The 1803175 is suited for roughing and finishing passes where a true 90-degree wall is required. Its coarse pitch configuration and three-insert layout make it effective on steel, cast iron, and similar ferrous workpiece materials. The through-coolant design supports higher feed rates and extended insert life in production environments. Typical applications include face milling of structural components, mold bases, and machine-tool parts in both job-shop and production-floor settings.

Key Features

• 2-inch maximum cutting diameter with a 0.394-inch maximum depth of cut
• 3/4-inch arbor hole diameter for standard milling machine arbor fitment
• Three-insert coarse-pitch body accepts BGHX 15L5 style indexable inserts
• 0/90 degree lead angle produces true square-shoulder profiles
• 24-degree positive rake angle reduces cutting forces and heat generation
• Through-coolant port supports extended insert life and higher feed rates

Compatibility

Designed to accept BGHX 15L5 style indexable inserts as part of the Kennametal Fix-Perfect series milling system.

Installation Notes

Installation should be performed by a qualified machinist following the machine tool manufacturer's spindle and arbor torque procedures. Ensure the machine spindle is fully stopped and locked out before mounting or removing the cutter body. Verify insert seating and clamp screw engagement before initiating any cut. Inspect insert pockets and seating surfaces for chips or debris prior to each insert change.
