Kennametal 1133236 Cap Screw Indexables M10 Socket Head

Product Description

The KENNAMETAL 1133236 is a cap screw designed for securing indexable inserts in cutting tool holders and tooling bodies. It features an M10 thread size with a socket head drive and a flat point, making it suited for the precise clamping loads required in indexable tooling assemblies. The overall length is 10 millimeters. At 0.01 pounds, the fastener is a low-mass hardware component, but its role in maintaining insert position and cutting stability is critical. Installation and replacement are performed by machinists and toolroom technicians as part of routine insert changes or tooling maintenance.

This cap screw is used in CNC machining centers, lathes, and milling operations wherever indexable insert tooling is employed. It is a replacement or spare hardware item kept on hand for tool assemblies that see frequent insert changes. The socket head design allows access with a standard hex key in tight toolholder pockets. This screw is sold individually with a minimum order quantity of 10 units, making it practical to stock as a consumable maintenance item alongside indexable inserts.

Key Features

• M10 thread size for compatibility with indexable tooling assemblies requiring that thread standard
• Socket head drive type allows hex key installation in confined toolholder geometries
• Flat point design provides stable seating against insert clamping surfaces
• 10 millimeter overall length suited to shallow-pocket indexable clamp applications
• Lightweight at 0.01 pounds, minimizing added mass to tooling assemblies

Compatibility

Designed as an OEM-style replacement cap screw for indexable insert toolholders requiring an M10 socket head cap screw with a flat point and 10 millimeter overall length.

Installation Notes

Installation is performed by machinists or toolroom technicians during insert changes or tooling assembly. Always ensure the toolholder is removed from the spindle and the machine is in a safe, powered-down state before servicing indexable hardware. Use a properly sized hex key to avoid rounding the socket head. Do not overtighten, as excess torque can damage the thread in the toolholder body or distort insert seating.
