KALAS 460015.02.010 Underground Feeder Cable

Product Description

The KALAS 460015.02.010 is a reliable underground feeder cable designed for direct burial. This product features two ten AWG bare copper conductors that are insulated with PVC. It is suitable for underground feeder circuits and branch circuits, complying with UL 493 and NEC Article 340. This cable is sunlight resistant and can withstand temperatures from negative twenty-five to sixty degrees Celsius.

• Conductor material: Bare copper
• Insulation material: PVC
• Suitable for direct burial installations

Product Highlights

This cable is versatile and meets industry standards for safe underground use.

Product Information

Standard Information

• Conductor Size: 10 AWG
• Number of Conductors: 2

Technical Specifications

• Voltage Rating: 600 Volt AC
• Type: Direct Burial, Underground Feeder
• Stranding: Solid
• Insulation Material: PVC
• Outer Diameter: 0.23 inches x 0.46 inches
• Length: 500 feet
• Weight: 140 pounds per 1000 feet
• Temperature Rating: -25 to 60 degrees Celsius
• Approval: UL 493/83, NEC
• Color Code: Black, White, Red, Gold
• UL Listed: Yes
• Diameter - Outside: 227/1000 inches
