Johnson Controls VG1845CP 3-Way Ball Valve Stainless Steel 1 Inch 18.7 Cv

Product Description

The Johnson Controls VG1845CP is a 1 inch three-way ball valve designed for use in HVAC systems. It regulates the flow of hot or chilled water, and in some models, low-pressure steam. The VG1845CP ball valve is part of the VG1000 Series, available in sizes from 1/2 inch to 2 inches.

• Graphite-Reinforced Polytetrafluoroethylene (PTFE) Seats provide durability.
• Ethylene Propylene Diene Monomer (EPDM) Double O-ring Steam Seal ensures leak-free performance.
• 200 psi Closeoff Pressure Rating assures tight shutoff.

Product Highlights

This Johnson Controls VG1845CP three-way ball valve features a stainless steel construction for durability and reliability. It provides precise control over the flow of HVAC system fluids and can handle fluid temperatures ranging from -22 to 284 degrees Fahrenheit.

Product Information

Standard Information

• Manufacturer: Johnson Controls
• Brand: Johnson Controls
• Model: VG1845CP

Technical Specifications

• Valve Type: 3-Way
• Material: Stainless Steel Trim
• Connection Size: 1 inch
• Connection Type: (F)NPT
• Coefficient of Volume (Cv): 18.7
• Closeoff Pressure: 200 psi
• Safe Working Steam PSI: 15 with Thermal Spacer
• Safe Working Water PSI: 580 psi
• Temperature Range: -22 to 284 degrees Fahrenheit
• Power Source: Electric Actuator
