Johnson Controls VG1845BL+910HGC Valve Assembly 3/4 in

Product Description

The Johnson Controls VG1845BL+910HGC valve assembly controls fluid flow in HVAC systems. It features a 3/4" NPT connection, a three-way configuration, and a 7.3 Cv flow coefficient. Designed for use with chilled water, hot water, 50% glycol, and 15 psig steam (stainless trim models only).

• Minimum 200,000 full cycle life expectancy
• Compatible with water, glycol, and low-pressure steam
• Equal percentage flow characteristics

Product Highlights

This valve assembly is used in combination with spring return and non-spring return direct-coupled actuators from Johnson Controls.

Product Information

Standard Information

• Brand: JOHNSON CONTROLS
• Manufacturer Part Number: VG1845BL+910HGC

Technical Specifications

• Type: Assembly
• Connection: NPT
• Actuator Type: Electric
• Cv: 7.3 CV
• Fail-Safe: Non-Spring Return
• Supply Voltage (Nominal): 24 VAC
• Trim Material: Stainless Steel
• Pattern: 3-way
• Size: 3/4 in
• Control Signal: Two Position, Floating, Analog
• MPN: VG1845BL+910HGC
• Brand: JOHNSON CONTROLS
• Control Input: Modulating
• Control Valves Type: Ball Valve
• Spring Return: Non-Spring Return
• Valve Size: 0.75" - 3-Way
• Voltage: 24V
• Manufacturer: Johnson Controls
