Johnson Controls VG1245CLH943GGB Ball Valve Assembly 2 Way 1 in.

Product Description

The Johnson Controls VG1245CLH943GGB is a two-way ball valve assembly designed for reliable operation in various HVAC applications. This model features a one-inch size, forged brass body, stainless steel ball, and a blowout-proof stem. It comes with a direct-mount electric actuator, a spring return mechanism rated at twenty-seven lb-in, and operates on twenty-four VAC with zero to ten VDC for proportional control.

• Maintenance-free design
• High cycle performance over two hundred thousand full stroke cycles
• Effective in iron-oxide contaminated water environments

Product Highlights

This ball valve assembly is built to last, managing hot water, chilled water, glycol solutions, and saturated steam for HVAC systems. It is suitable for various load conditions, offering accurate control and a wide range of functionality.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG1245CLH943GGB

Technical Specifications

• Close-Off Pressure: 200 psig
• Operating Conditions: -22 F to 140 F
• Power Consumption: 5.1 VA Running, 2.8 VA Holding
• Flow Characteristic: Equal Percentage
• Auxiliary Switch: 1 x SPDT
• Electrical Connection: 48 in. 18 AWG Appliance Cables
• Service: Hot Water, Chilled Water, Glycol Solutions
• Housing: NEMA 2, IP54
