Johnson Controls VG1241FT+958GGC Ball Valve Assembly, 2 Way, 2 in.

Product Description

The Johnson Controls VG1241FT+958GGC is a two-way ball valve assembly designed for HVAC systems. This valve features a maintenance-free design and operates effectively in various water conditions. It is suitable for both hot and chilled water applications, making it versatile for different setups.

• 73.7 Cv flow rate
• Direct mount electric actuator with spring return
• Compatible with a range of fluid temperatures

Product Highlights

This valve ensures accurate flow control and is built to withstand iron-oxide contaminated water.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG1241FT+958GGC

Technical Specifications

• Housing: NEMA 2, IP54
• Service: Hot Water, Chilled Water, 50/50 Glycol Solution
• Auxiliary Switch: 2 x SPDT
• Power Consumption: 7.9 VA Running, 5.5 VA Holding
• Close-Off Pressure: 200 psig
• Flow Characteristic: Equal Percentage
• Operating Conditions: -40 F To 140 F (-40 C To 60 C)
• Electrical Connection: 48 in. 18 AWG Appliance Cable With Integral 3/8 in. FMC Connectors
