Johnson Controls VG1241DP+938BGC Ball Valve Assembly 2 Way 1-1/4 In.

Product Description

The Johnson Controls VG1241DP+938BGC is a two-way ball valve assembly designed for HVAC applications. It has a pipe size of one and one-quarter inches. This valve features a maintenance-free design, allowing for long-term usage without the need for frequent servicing.

• Constructed from forged brass for durability
• Compatible with hot and chilled water systems
• Direct mount electric actuator for easy installation

Product Highlights

This valve is built to perform efficiently in various load conditions with a fluid temperature range from twenty-three degrees Fahrenheit to two hundred three degrees Fahrenheit.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG1241DP+938BGC

Technical Specifications

• Housing: NEMA 2, IP54
• Service: Hot Water, Chilled Water, 50/50 Glycol Solution
• Auxiliary Switch: 2 x SPDT
• Power Consumption: 6.1 VA Running, 1.2 VA Holding
• Close-Off Pressure: 200 psig
• Flow Characteristic: Equal Percentage
• Operating Conditions: -40 F To 140 F (-40 C To 60 C)
• Electrical Connection: 48 in. 18 AWG Appliance Cable With Integral 3/8 in. FMC Connectors
