Johnson Controls P32AC-2C Differential Pressure Switch 0.05/5 WC Adjustable Mounting Bracket

Product Description

The Johnson Controls P32AC-2C is a differential pressure switch designed for HVAC systems. It measures air pressure differences in ducts, helping to control airflow efficiently. The switch activates electric heaters when airflow stops, ensuring optimal performance of heating systems.

• Adjustable set point from 0.05 inches to 5.0 inches water column
• Includes U bracket for versatile mounting options
• Sensitive switching differential enhances system reliability

Product Highlights

This switch is suitable for applications such as air proving with electric duct heaters and for monitoring maximum airflow in variable air volume systems.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: P32AC-2C

Technical Specifications

• Ambient Operating Temperature: -40 to 165°F
• Max Pressure: 1 PSIG
• Set Point: Factory set for optimal performance
• Diaphragm Material: Buna-N
• Mounting Options: Direct or with U bracket
• Connector Type: High Pressure, Metal, 1/8 Female NPT
• Weight: 1.205 lbs
• Dimensions: 6.55 inches x 5.2 inches x 3.8 inches
