Johnson Controls P100CP-165C Pressure Switch Open at 600 PSIG

Product Description

The Johnson Controls P100CP-165C pressure switch is a compact and economical option for direct-mount applications. This device operates with a snap-action mechanism, opening at six hundred psig and closing at four hundred seventy-five psig. It features a pressure rise switch action suitable for various refrigeration and air conditioning applications.

• Open at six hundred psig and close at four hundred seventy-five psig
• Includes a quarter-inch diameter female flare pressure port
• Designed for repeatable and precise pressure control

Product Highlights

This pressure switch is effective for controlling motors and loads in HVAC systems.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: P100CP-165C

Technical Specifications

• Switch Action: Open on Pressure Rise
• Application: High Pressure
• Cut-In PSI: 475
• Cutout PSI: 600
• Reset Type: Auto
• Type: High Pressure
• Style: Encapsulated
• Connection: 1/4 F Flare
• Switching: SPST
• Electrical Rating: 5.8 FLA @ 115VAC; 2.9 FLA @ 230VAC
