Johnson Controls C450SBN-3C System 450 Relay Output Expansion Module 1 Stage

JOHNSON CONTROLS
Brand: JOHNSON CONTROLS
SKU: C450SBN-3C
Availability: In Stock

Ships same day if ordered by 12 pm
$77.13
$77.13
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

Johnson Controls C450SBN-3C is a System 450 relay output expansion module that provides one SPDT line-voltage relay output for HVAC and industrial process control applications. The module integrates with modular System 450 controls to add a single relay stage and supports field-configurable operation with DIN mounting and a NEMA 1 enclosure. It accepts 24 VAC input and handles full load currents of 9.8A at 120 VAC and 4.9A at 240 VAC.

  • One SPDT line-voltage relay output for a single-stage expansion
  • 24 VAC input; full load capacity 9.8A @ 120 VAC and 4.9A @ 240 VAC
  • DIN mounting, NEMA 1 enclosure, LCD display, compatible with System 450 modules

Product Highlights

Single SPDT relay output expansion for System 450; 24 VAC input; DIN mount, NEMA 1 enclosure

Product Information

Standard Information

  • Brand: JOHNSON CONTROLS
  • Manufacturer Part Number: C450SBN-3C
  • Country of Origin: Mexico
Technical Specifications
Brand
Johnson Controls
Manufacturer Part Number
C450SBN-3C
Product Type
Relay output expansion module (System 450)
Module Function
Adds one relay stage to System 450 control modules
Relay Type
SPDT (single pole double throw) line-voltage relay
Number of Relay Outputs
1
Input Voltage
24 VAC
Full Load Amps @ 120VAC
9.8A
Full Load Amps @ 240VAC
4.9A
Switch Action
Open/Close on Rise
Display Type
LCD
Mounting Type
DIN
Enclosure Rating
NEMA 1
Compatible With
A99, TE-6300, HE-67 sensors
Dimensions (H x W x D)
5 in x 2.5 in x 2.5 in
Package Dimensions (L x H x W)
6 in x 4 in x 4 in
Country of Origin
Mexico
