Jay R Smith 1010Y03(-C-CIDG) 3 in Floor Drain Cast Iron

Product Description

The JAY R SMITH 1010Y03(-C-CIDG) is a 3-inch Y-body floor drain assembly configured with underdeck clamping ring hardware and a galvanized cast iron dome strainer. Designed for below-deck drain installations, this unit uses the -C underdeck clamp option to secure the drain body to the underside of the deck membrane or slab form, ensuring a watertight connection at the drain collar. The galvanized cast iron dome strainer provides corrosion resistance and durability in wet service environments. Licensed plumbers install this drain in commercial and institutional construction projects where waterproofing membrane integrity is critical.

This drain assembly is suited for commercial and institutional floor drain applications including mechanical rooms, restrooms, kitchens, and utility areas where an underdeck clamp configuration is specified. The Y-body design of the 1010 series accommodates standard 3-inch drain piping. The included cast iron dome strainer with galvanized finish resists corrosion in continuously wet or intermittently flooded service conditions typical of these environments.

Key Features

• 3-inch drain outlet in Y-body configuration for standard drain piping connections
• Underdeck clamp (-C) option secures drain body to deck underside for membrane waterproofing installations
• Galvanized cast iron dome strainer (-CIDG) provides corrosion resistance in wet service conditions
• 1010 series body design suited for commercial and institutional floor drain applications
• Factory-assembled options (-C-CIDG) reduce field configuration time

Compatibility

Designed as an OEM-configured replacement or new-installation drain unit within the JAY R SMITH 1010 series floor drain product family, compatible with standard 3-inch drain piping systems.

Installation Notes

Installation is performed by a licensed plumber in accordance with the applicable local plumbing code and IPC requirements for floor drain placement and waterproofing membrane integration. Shut off all water supply to the affected area before beginning work. The underdeck clamp must be properly secured to the deck structure before membrane material is applied to ensure a watertight seal at the drain collar. Do not overtighten the clamp ring against a cured waterproofing membrane, as this may compromise membrane integrity.

Technical Specifications

• Drain Outlet Size: 3 inches
• Body Type: Y-body
• Clamp Type: Underdeck clamp (-C option)
• Strainer Type: Cast iron dome, galvanized (-CIDG option)
• UPC: 727753402225

Standard Information

• Brand: JAY R SMITH
• Manufacturer Part Number: 1010Y03(-C-CIDG)
