Jackson Safety 14772 Contour Marker Combo Adaptor

Product Description

The JACKSON SAFETY 14772 is a contour marker combo adaptor designed for laying out structural steel, pipes, and joints in the field. The tool uses an X-shaped frame, a calibrated angle protractor, and a triple-jointed marker arm with bracket to mark cut lines at any angle without complex math or trial cuts. It works on pipe diameters from 1.5 inches to 18 inches and on structural steel members up to 18 inches, in both right-side-up and upside-down positions. A soapstone crayon is included. Pipefitters, plumbers, and ironworkers use this tool to reduce material waste and speed up layout work on tees, wyes, crosses, and elbows.

This contour marker is suited for residential and commercial mechanical and structural applications where accurate pipe and steel layout is required. It handles lateral arrangements at any angle, making it useful for complex joint configurations without requiring the cut-and-test method. The combo adaptor designation indicates compatibility with the 2-size range covered by this unit, spanning the full 1.5-inch to 18-inch diameter range.

Key Features

• Covers pipe diameters from 1.5 inches to 18 inches and structural steel members up to 18 inches
• X-shaped frame with calibrated angle protractor for precise angular layout
• Triple-jointed marker arm and bracket supports tees, wyes, crosses, and elbows at any angle
• Eliminates complex math and cut-and-test approaches, reducing material waste
• Works in right-side-up and upside-down positions for versatile field use
• Includes soapstone crayon for immediate use out of the box

Compatibility

Designed for use on pipe from 1.5 inches to 18 inches in diameter and structural steel members up to 18 inches; suitable for a wide range of pipe materials and joint types including tees, wyes, crosses, and elbows of any angle.

Installation Notes

This tool is used by pipefitters, plumbers, and structural ironworkers during the layout and fabrication phase before cutting. Ensure the work surface is stable and the pipe or member is properly supported before marking. Follow applicable codes such as IFGC or IPC for pipe system requirements in your jurisdiction. No power source is required for operation of this layout tool.

Technical Specifications

• Pipe Diameter Range: 1.5 inches to 18 inches
• Structural Steel Capacity: Up to 18 inches
• Includes: Soapstone crayon
• Unit of Measure: Each
• Minimum Order Quantity: 1
• UPC: 626053604745

Standard Information

• Brand: JACKSON SAFETY
• Manufacturer Part Number: 14772
