Iscar 5620610 Corner Chamfer End Mill 3 Flute Solid Carbide

Product Description

The ISCAR 5620610 is a solid carbide corner chamfer end mill designed for precision chamfering and edge-breaking operations on ferrous and non-ferrous materials. It features a 0.2362-inch cutting diameter, a 0.5118-inch length of cut, and a 0.0118-inch chamfer width. The three-flute geometry provides a balance of chip evacuation and surface finish quality. A TiAlN coating extends tool life in high-temperature cutting environments. The right-hand cutting and right-hand flute spiral direction suit standard CNC and manual milling setups. Machinists in job shop, aerospace, and precision manufacturing environments use this tool for consistent chamfer production.

This end mill is suited for chamfering and edge-prep operations on milled components where a controlled, repeatable chamfer width is required. The fine pitch, regular-length configuration fits compact workpiece geometries. The 6 mm shank diameter accommodates standard collet chucks and end mill holders. Centercutting capability allows plunge entry where the application requires it. The 38-degree helix angle promotes smooth chip flow at typical CNC feed and speed parameters for carbide tooling.

Key Features

• 0.0118-inch chamfer width for precise, controlled edge chamfering
• TiAlN coating for extended tool life in elevated-temperature cutting conditions
• Three right-hand spiral flutes with fine pitch for improved surface finish
• Centercutting design allows direct plunge entry
• Solid carbide construction provides rigidity and wear resistance
• 38-degree helix angle promotes efficient chip evacuation

Compatibility

Designed as an OEM-style solid carbide corner chamfer end mill for use in standard 6 mm collet chucks and end mill holders on CNC machining centers and manual milling machines.

Installation Notes

Installation should be performed by a qualified machinist or CNC operator. Ensure the spindle is fully stopped and the machine is in a safe state before mounting or removing the tool. Seat the 6 mm shank fully and evenly in the collet or holder and torque the retention mechanism to the toolholder manufacturer specification. Verify runout with a dial indicator before starting a production run to prevent premature tool wear or part damage.
