Iscar 5607524 Milling Insert IQ845 Syhu 0704ADN-MM IC5400

Product Description

The ISCAR 5607524 is a solid carbide milling insert designated IQ845 SYHU 0704ADN-MM in grade IC5400, designed for use in DOVEIQMILL-series face and shoulder milling cutters. The insert features a square shape with a 90-degree included angle, 8 cutting edges, and a T-Land cutting edge style with a negative rake and neutral hand orientation. The IC5400 grade uses an MTCVD coating process with a TiCN, Al2O3, and TiN multilayer stack, making it well suited for steel and stainless steel machining applications. A 1/32-inch corner radius and a maximum depth of cut of 0.181 inches allow for precise, controlled material removal in production milling operations. The insert is held by screw clamping and is compatible with the IQ845 cutter series. Licensed machinists and CNC tooling technicians are the primary installers.

This insert is intended for milling steel and stainless steel workpieces in both roughing and semi-finishing operations. It is suited for use in production shops, job shops, and manufacturing environments running CNC vertical or horizontal machining centers. The MM chip breaker geometry is optimized for medium machining conditions. The insert is single-sided and carries ANSI and ISO 13399 compliance designations. Compatible cutter series is the IQ845 DOVEIQMILL platform.

Key Features

• 8 cutting edges per insert for extended tool life and reduced cost per edge
• IC5400 grade with MTCVD TiCN, Al2O3, and TiN multilayer coating for wear resistance in steel and stainless steel
• T-Land cutting edge style with negative rake for edge strength and stability
• MM chip breaker geometry optimized for medium milling conditions
• 90-degree included angle with 1/32-inch (0.0315-inch) corner radius
• Compliant with ANSI and ISO 13399 standards

Compatibility

Designed for use with the IQ845 DOVEIQMILL cutter series. ANSI code: IQ845 SYHU 0704ADN-MM IC5400. ISO code: IQ845 SYHU 0704ADN-MM. Screw-held mounting method. Primary workpiece material codes P and M cover steel and stainless steel applications.

Installation Notes

Installation is performed by qualified CNC tooling technicians or machinists. The machine spindle must be fully stopped and locked out before changing inserts. Use the appropriate torx or hex key as specified by the cutter body manufacturer for the clamping screw. Inspect the insert pocket and clamping screw for wear or damage before seating a new insert.
