Iscar 5606381 Milling Insert IC830 Trigon Altin Pvd

Product Description

The ISCAR 5606381 is a solid carbide trigon milling insert carrying the ANSI designation H600 WXCU 040310HP IC830, designed for high-feed face milling operations in the HELI6FEED series. Coated with AlTiN and TiN via a PVD Sumotec process, this double-sided insert provides 6 cutting edges and carries a negative rake geometry with a zero-degree relief angle. With an inscribed circle of 0.2461 inches, a thickness of 0.122 inches, and a maximum depth of cut of 0.1626 inches, it is engineered for productive material removal in demanding production environments. A licensed machinist or CNC tooling specialist installs this insert into compatible EWX-series cutter bodies.

This insert is intended for machining steel, stainless steel, superalloys, and titanium, covering ISO material codes P, M, and S. It is well suited for high-feed milling applications in aerospace, energy, and general manufacturing where tool life and edge consistency on difficult materials are critical. The right-hand, screw-held design mates with EWX-series cutter bodies. The HP chip breaker geometry is optimized for sharp-edge cutting action at high feed rates with reduced cutting forces across all primary workpiece material categories.

Key Features

• Double-sided trigon insert with 6 usable cutting edges for extended tool economy
• IC830 grade with AlTiN and TiN PVD Sumotec coating for wear and heat resistance
• HP chip breaker with sharp cutting edge style reduces cutting forces on steel and superalloys
• Negative rake, zero-degree relief angle geometry suits high-feed milling strategies
• Right-hand orientation, screw-held mounting for positive seating in EWX cutter bodies
• Compliant with ANSI and ISO 13399 standards for interoperability and tooling data integration

Compatibility

Designed for use in ISCAR EWX-series cutter bodies within the HELI6FEED platform. Compatible with workpiece materials classified under ISO codes P (steel), M (stainless steel), and S (superalloys and titanium).

Installation Notes

Installation is performed by a qualified machinist or CNC tooling technician. Always power down and lock out the spindle before seating or removing inserts. Use the correct torque driver specified by the cutter body manufacturer for the insert clamping screw — do not overtighten, as this can fracture the carbide substrate. Inspect the insert pocket and clamping screw for wear or debris before installing a fresh edge.
