Iscar 5507805 Cnmg 432-PP IC8250 Turning Insert

Product Description

The ISCAR 5507805 is a CNMG 432-PP indexable turning insert in the Isoturn series, designed for external and internal turning operations on CNC lathes and turning centers. Built from solid carbide with a CVD-applied multilayer coating of TiCN, Al2O3, and TiN, this insert is engineered for productive cutting in steel and stainless steel workpiece materials. The 80-degree diamond insert shape (Shape Code C) provides two usable cutting edges per insert. The insert measures 12.9 mm (0.508 inches) in length with a 0.5-inch inscribed circle and a 1/32-inch corner radius, and it uses a clamp and pin holding method in compatible toolholders.

The ISCAR 5507805 is suited for general turning, facing, and boring applications on both steel (ISO P) and stainless steel (ISO M) workpiece materials. The PP chip breaker geometry supports positive rake cutting action, which helps control chip formation and reduces cutting forces during moderate to roughing passes. Maximum depth of cut reaches 3.99 mm (0.157 inches). This insert fits CNMG-style toolholders commonly used in production turning environments in manufacturing and machine shops.

Key Features

• Solid carbide substrate with CVD multilayer coating: TiCN, Al2O3, TiN — improves wear resistance and thermal stability
• IC8250 manufacturer grade — optimized for steel and stainless steel cutting applications
• PP chip breaker with positive rake geometry for controlled chip evacuation
• 80-degree diamond insert shape with clamp and pin holding for rigid, repeatable seating
• Supports boring as a multi-use application in addition to standard turning
• Conforms to ISO 13399 tooling data standards for compatibility with modern CAM and tool management systems

Compatibility

Designed as a direct-fit replacement for CNMG 432-PP style indexable toolholders using clamp and pin insert retention. Compatible with ISO P (steel) and ISO M (stainless steel) workpiece materials per ISO classification. Verify toolholder clamping style and insert pocket dimensions before installation.

Installation Notes

Indexable turning inserts are installed and replaced by qualified machinists or toolroom personnel following the machine tool manufacturer and toolholder OEM specifications. Power down and lock out the machine before changing inserts. Use the correct torque wrench for the clamping screw as specified by the toolholder manufacturer — do not overtighten or undertighten the clamp screw. Inspect the insert pocket and clamp components for wear or damage each time an insert is indexed or replaced.
