IPS CORPORATION 83553 Pneumatic Test Plug 3

Product Description

The IPS CORPORATION 83553 is a 3 pneumatic test plug designed for use in DWV testing. This product is part of the Test-Tite VIP Series. It features a robust natural rubber body made using a precision vulcanization process. The plug is equipped with a high-performance Schrader valve for easy inflation, which simplifies the testing process.

• Nominal size of 3 inches.
• Includes a galvanized steel chain for secure handling.
• ABS plastic ring tag for easy identification.

Product Highlights

The IPS CORPORATION pneumatic test plug is engineered for reliable sealing and durability, making it suitable for various plumbing applications.

Product Information

Standard Information

• Product Code: 83553

Technical Specifications

• Nominal Size (inches): 3
• Chain Length: 1 ft
• Minimum Pipe Diameter (inches): 2.25
• Maximum Pipe Diameter (inches): 3.25
• Plug Diameter (inches): 2.56
• Plug Length (inches): 3.45
• Overall Plug Length (inches): 4.57
• Inflation Pressure (psig): 35
• Water Head (feet): 30
• Air Pressure (psig): 13
• Units per Case: 6
