Io Hvac Controls MBD-1212 Manual Balancing Damper 12x12

Product Description

The IO HVAC CONTROLS MBD-1212 is a manual balancing damper designed for airflow regulation in ducted HVAC distribution systems. It features a 12 x 12 inch duct opening size and includes a locking quadrant that holds the blade position after adjustment, preventing unintended movement during normal system operation. The unit ships at 6.45 pounds and has an overall package footprint of 14 inches wide by 19 inches tall by 8 inches deep. Licensed HVAC technicians and sheet metal installers use this damper to balance air delivery across multiple zones or branches in residential and light commercial forced-air systems.

The MBD-1212 is suited for installation in rectangular duct runs where manual airflow balancing is required. Common applications include multi-zone residential systems, commercial VAV bypass configurations, and new construction duct installations where each branch requires independent volume control. The locking quadrant makes it practical for supply branches that are set once during system commissioning and left in position without an actuator.

Key Features

• 12 x 12 inch duct opening for standard rectangular duct sizing
• Locking quadrant holds blade position after manual adjustment
• No actuator or control wiring required for operation
• Compact package depth of 8 inches for installation in tight plenum and duct spaces
• Ships at 6.45 pounds for straightforward single-technician handling

Compatibility

Designed as an OEM-style manual balancing damper for use in 12 x 12 inch rectangular duct systems in residential and light commercial forced-air HVAC applications.

Installation Notes

Installation should be performed by a qualified HVAC technician or licensed sheet metal contractor in accordance with SMACNA duct construction standards and applicable local mechanical codes. Shut down the air handling unit and confirm the system is de-energized before cutting into existing ductwork. Secure the damper to the duct with sheet metal screws around the flange perimeter and verify the quadrant moves freely through its full range before final locking. Do not compress or restrict the damper blade beyond the design range of the quadrant stop.
