Intellinet 156-202/p/gr Cat 5e Plenum Cable 1000 Ft

Product Description

The INTELLINET 156-202/p/gr is a 1000-foot spool of Category 5e plenum-rated (CMP) networking cable designed for structured cabling installations in air handling and return air spaces. Built with four unshielded twisted pairs of 24 AWG solid bare copper conductors, it supports bandwidths up to 350 MHz and meets ANSI/TIA-568-C.2 performance standards. The green PVC-free plenum jacket provides clear visual identification during installation and satisfies fire-resistance requirements for use in plenum air spaces. ETL/UL listing and RoHS compliance are included. Licensed electricians and low-voltage cabling contractors typically handle installation in commercial and institutional environments.

This cable is suited for commercial office buildings, data centers, healthcare facilities, and integrated AV or security networks where plenum fire ratings are required by local code. The CMP rating makes it appropriate for runs through ceilings, raised floors, and HVAC return air plenums without the need for conduit in many jurisdictions. The 1000-foot spool length supports full horizontal runs in structured cabling systems built to ANSI/TIA-568 specifications.

Key Features

• CMP plenum rating meets fire-resistance requirements for air handling spaces
• Four unshielded twisted pairs (UTP) of 24 AWG solid bare copper conductors
• Supports bandwidths up to 350 MHz for high-performance Cat 5e data transmission
• Meets and exceeds ANSI/TIA-568-C.2 performance standards
• ETL/UL listed for safety compliance
• RoHS compliant for environmental standards
• Green jacket for easy visual identification in the field

Compatibility

Designed as an OEM-style replacement and standard installation cable for Cat 5e structured cabling systems using RJ-45 patch panels, keystone jacks, and network switches in plenum-rated environments.

Installation Notes

Installation should be performed by a licensed low-voltage or electrical contractor in accordance with NEC Article 800 and applicable local codes. Verify plenum-rated pathways before pulling cable, and do not exceed the minimum bend radius or maximum pull tension specified for Cat 5e UTP cable. Avoid running cable parallel to high-voltage conductors to minimize electromagnetic interference. Terminate with Cat 5e-rated connectors and test each run with a certified cable tester after installation.

Technical Specifications

• Cable Category: Cat 5e
• Plenum Rating: CMP
• Conductor Pairs: 4 pair (UTP)
• Conductor Gauge: 24 AWG solid bare copper
• Bandwidth: 350 MHz
• Cable Length: 1000 feet
• Jacket Color: Green
• Standards: ANSI/TIA-568-C.2
• Certifications: ETL/UL listed, RoHS compliant

Standard Information

• Brand: INTELLINET
• Manufacturer Part Number: 156-202/p/gr
