Ingersoll Cutting Tools 6137498 Replaceable Drill Tip 1.5in

Product Description

The INGERSOLL CUTTING TOOLS 6137498 is a replaceable drill tip designed for use with modular drilling systems in demanding metal-removal applications. Built from solid carbide in the IN2505 grade and coated via PVD process with TiAlN and Titanium Nitride, this tip delivers hardness and heat resistance needed for production drilling in tough materials. It features a 140-degree point angle for accurate entry and self-centering, and a flat-bottom point type suited for through-hole and blind-hole work. The tip weighs 1.57 pounds and is installed by twist-locking into compatible LPA-series drill bodies. Coolant-through capability supports chip evacuation and thermal control at the cutting edge. Machinists and toolroom professionals in production and job-shop environments are the primary installers.

This tip is rated for primary use in steel, stainless steel, and high-temperature alloys, covering ISO material codes P, M, and S. It fits into the LPA series modular drill platform and carries ISO designation LPA3810R01 IN2505. The insert seat size is 38, and the flute length is 11.07 millimeters. It is well suited for applications where consistent hole quality and extended tool life in difficult-to-machine materials are required. This tip is sold individually with a minimum order quantity of one piece.

Key Features

• Solid carbide construction in IN2505 grade for strength and wear resistance in ferrous and high-temp alloys
• PVD-applied TiAlN and Titanium Nitride coating for elevated heat resistance and reduced tool wear
• 140-degree point angle with flat-bottom point type for accurate, self-centering entry
• Coolant-through design to flush chips and manage heat at the cutting zone
• Twist-lock insert holding method for fast, repeatable tip changes without removing the drill body
• Covers ISO material groups P, M, and S: steel, stainless steel, and high-temperature alloys

Compatibility

Designed for use with LPA-series modular drill bodies. ISO designation LPA3810R01 IN2505. Insert seat size 38. Verify holder compatibility with the seat size and series designation before installation.

Installation Notes

Installation is performed by machinists or toolroom personnel following standard modular tooling procedures. Power down and lock out the machine spindle before handling or replacing drill tips. Twist-lock the tip firmly into the seated position and confirm full seating before initiating a cut. Inspect the insert seat for chips, debris, or wear before installing a replacement tip, as seat condition directly affects tip retention and hole accuracy.
