ILSCO CSWD-1-38-1 Compression Cable Lug

Product Description

The ILSCO CSWD-1-38-1 is a compression cable lug designed for use with cables ranging from one to six AWG. It features a three-eighth inch bolt hole for secure installation.

• High strength seamless copper tubing for maximum conductivity
• Long barrel length with chamfered entry for easy cable insertion
• Color-coded for easy identification and application

Product Highlights

This cable lug provides excellent crimping characteristics and low contact resistance for reliable electrical connections. Ideal for grounding and bonding applications.

Product Information

Standard Information

• Manufacturer: ILSCO
• UPC: 783669635218

Technical Specifications

• Approval: UL 453G, UL 467, UL 486A/B, CSA
• Barrel Length: 0.625 Inch
• Barrel Type: Standard
• Color: Green
• Conductor Material: Copper
• Conductor Size: 1 AWG
• Die Index: I-37
• Material: Seamless Electro-Tin Plated Copper
• Number Of Pad Holes: 2
• Pad Hole Spacing: 1 Inch
• Pad Size: 1.937 Inch L x 0.673 Inch W x 0.109 Inch Thk
• Stud Size: 3/8 Inch
