Ilsco 25002 Thin Wall 1/16in Exp. I 8 ft Disc

Product Description

The ILSCO 25002 is a thin-wall polyolefin heat-shrink tubing recognized to UL 224 and C22.2 No. 198.1, rated for 600 V and supplied on a disk dispenser in an 8 ft cut length. It offers a 2:1 shrink ratio with a minimum expanded diameter of 0.063 in and a maximum recovered diameter of 0.031 in, suitable for insulating terminations, splices, and wire management on 30–24 AWG conductors.

• Thin-wall polyolefin tubing, 2:1 shrink ratio; minimum expanded diameter 0.063 in and maximum recovered diameter 0.031 in
• Rated 600 V with UL 224 recognition and C22.2 No. 198.1 (CSA) compliance; thickness 0.017 in
• Supplied on a disk dispenser as an 8 ft (96 in) cut length for insulation of terminations, splices, and cable management

Product Highlights

Thin-wall polyolefin heat-shrink tubing, 2:1 shrink ratio, 8 ft disc, rated 600 V, UL 224 and C22.2 No. 198.1 compliant

Product Information

Standard Information

• Brand: ILSCO
• Manufacturer Part Number: 25002
