Ideal Industries 89-212 Terminal Strip, 30A 600V 12-Circuit

Product Description

The Ideal Industries 89-212 terminal strip is a robust solution for electrical connections. This 12-circuit terminal strip supports wire sizes from 22 to 10 AWG and accommodates a maximum current of thirty amps with a voltage rating of six hundred volts. It is designed for surface mounting, providing dependable performance in various electrical applications.

• 0.562 inch center spacing for versatile installation
• Corrosion-resistant screws and hardware enhance durability
• UL Recognized and CSA Certified for safety compliance

Product Highlights

This terminal strip is engineered to withstand harsh conditions, featuring a rugged polyester thermoplastic base that minimizes breakage risks. It is ideally suited for power distribution in commercial and industrial environments.

Product Information

Standard Information

• Manufacturer: Ideal Industries
• Part Number: 89-212

Technical Specifications

• Amperage Rating: 30 A
• Voltage Rating: 600 V
• Number of Terminals: 12
• Wire Size: 22-10 AWG
• Material: Polyester Thermoplastic/Steel
• Dimensions: 7.75 inches L x 1.33 inches W x 0.81 inches H
• Temperature Rating: -40 to 260 degrees F
• Torque Rating: 16 in-lb
• Mounting Type: Surface
• Flammability Rating: UL 94 V-0
• Country of Origin: Mexico
