Icp DLFEHAA12XBK Ductless Split Indoor Unit 12000 Btu 16 Seer

Product Description

The INTERNATIONAL COMFORT PRODUCTS DLFEHAA12XBK is a cooling-only ductless mini-split high wall indoor unit rated at 12,000 BTU/h and 16 SEER. It operates on 230-volt power and is designed for single-zone applications where dedicated cooling is required without a ducted distribution system. This unit mounts on an interior wall and connects to a compatible outdoor condensing unit via refrigerant line sets. HVAC technicians install and commission this equipment. The 16 SEER efficiency rating meets Energy Star thresholds common in many residential permit jurisdictions.

This indoor unit is suited for residential and light-commercial single-zone cooling applications, including bedrooms, offices, additions, server rooms, and other spaces where independent temperature control is needed. As a cooling-only unit, it does not provide heating, making it appropriate for climates where supplemental heat is handled by a separate system. Installation requires a compatible outdoor condensing unit; confirm system pairing before ordering.

Key Features

• 12,000 BTU/h cooling capacity for single-zone applications
• 16 SEER efficiency rating for reduced operating costs
• 230-volt operation compatible with standard mini-split electrical circuits
• Cooling-only design suited for warm-climate or supplemental-cooling installations
• High wall mount configuration for unobtrusive interior placement

Compatibility

Designed as an OEM-style cooling-only ductless mini-split high wall indoor unit requiring a separately purchased compatible outdoor condensing unit. Verify outdoor unit compatibility with INTERNATIONAL COMFORT PRODUCTS documentation before installation.

Installation Notes

Installation must be performed by a licensed HVAC technician holding the appropriate EPA Section 608 certification for refrigerant handling. Disconnect and lock out all electrical power to both indoor and outdoor units before servicing. Line set connections must be leak-tested and the system properly evacuated before charging. Local mechanical and electrical permits are typically required; consult applicable codes before beginning work.

Technical Specifications

• Cooling Capacity: 12,000 BTU/h
• SEER: 16.0
• Voltage: 230 volts
• System Type: Ductless Split, Cooling Only
• Mount Type: High Wall Indoor Unit
• Dimensions (L x W x H): 34 x 12 inches
• Weight: 23 pounds

Standard Information

• Brand: INTERNATIONAL COMFORT PRODUCTS
• Manufacturer Part Number: DLFEHAA12XBK
