Icm Controls ICM325HNC Head Pressure Control 24V (1 Pack)

Product Description

Icm Controls ICM325HNC is a head pressure control with a built-in 24-volt transformer and AC-only triac output for modulating condenser fan motor voltage. It accepts 115-460 V input and provides an output voltage range of 120-480 V. The unit includes adjustable hard start timing (0.1–5.0 seconds), triac output current range 0.1–10.0 A, and protections for low ambient and high-temperature conditions.

• Built-in 24 VAC transformer; AC-only triac output for motor modulation
• Input voltage 115–460 V; output voltage range 120–480 V
• Adjustable hard start timing 0.1–5.0 s; triac output 0.1–10.0 A; low ambient and high-temperature protections

Product Highlights

Head pressure control with built-in 24 VAC transformer, wide input/output voltage range, adjustable hard start timing, and triac output 0.1–10 A.

Product Information

Standard Information

• Brand: ICM CONTROLS
• Manufacturer Part Number: ICM325HNC
• Country of Origin: United States
