ICM Controls ICM201B Delay-On-Make Timer 18-30 VAC 1.5 AMP R614-40

Product Description

ICM Controls ICM201B is a Delay-On-Make Timer designed for 18 to 30 VAC applications with a current capacity of 1.5 amps. This timer features a compressor lockout which helps prevent the compressor from short cycling. This protection is essential for extending the life of the compressor. The timer is easy to install with a simple two-wire hook-up and has a fixed delay timing of five minutes. It directly replaces several models including Mars 32390, Diversified ASC-500-5, and Supco TD735.

• Compressor lockout feature
• Prevents rapid short cycling
• Simple two-wire installation

Product Highlights

This timer simplifies the management of compressor cycles, ensuring proper operation and longevity.

Product Information

Standard Information

• Brand: ICM Controls
• MPN: ICM201B

Technical Specifications

• Voltage: 18-30 VAC
• Current Rating: 1.5 amps
• Timing Range: 5 Minutes Fixed Delay
• Part Type: Time Delay Fixed, Delay On Break
