Hunt Electronics hnc324g2-td 4MP Fixed Ir Dome Camera

Product Description

The HUNT ELECTRONICS hnc324g2-td is a 4-megapixel fixed dome IP camera designed for continuous surveillance in both indoor and outdoor environments. It captures at 4MP resolution using an H.265 codec for efficient bandwidth and storage use, and it features a 4mm fixed lens with a 2-axis adjustment range. Built-in infrared illumination supports day and night operation without supplemental lighting. Power over Ethernet (PoE) eliminates the need for a separate power run, simplifying installation in new and retrofit deployments. Security integrators and low-voltage technicians are the primary installers of this camera.

This camera suits residential and light commercial surveillance applications where a discreet dome form factor is preferred. It is well suited for soffit mounts, ceiling mounts, and direct wall mounts where the lens faces forward. The IP66-rated housing protects against dust and water intrusion, making it appropriate for covered outdoor locations. The IK10-rated housing provides resistance against physical impact and vandal attempts, supporting deployment in higher-risk areas such as entryways, parking structures, and retail spaces.

Key Features

• 4MP resolution with H.265 compression for reduced storage and bandwidth demands
• 4mm fixed lens with 2-axis adjustment for precise aiming during installation
• Infrared (IR) illumination for reliable day and night image capture
• Power over Ethernet (PoE) support for single-cable installation
• IP66-rated housing rated for outdoor weather exposure
• IK10-rated housing providing vandal-resistant protection
• Dual streaming and digital wide dynamic range (WDR) for flexible deployment

Compatibility

Designed as an OEM-style fixed dome IP camera compatible with standard PoE network video recorder (NVR) systems and video management software that support H.265 RTSP streams.

Installation Notes

Installation should be performed by a licensed low-voltage or security systems technician in accordance with local codes and NEC guidelines for low-voltage wiring. Power down the PoE switch port before connecting or disconnecting the camera. Note that this camera provides 2-axis lens adjustment only — if the installation requires the lens assembly to tilt laterally to achieve a level horizon, a pendant-style wall-mount bracket must be used rather than a direct surface mount. Verify that the mounting surface can support the camera weight and that all conduit or cable penetrations are sealed against moisture intrusion.

Technical Specifications

• Resolution: 4 megapixel
• Lens: 4mm fixed
• Video Compression: H.265
• Lens Adjustment: 2-axis
• Power Input: Power over Ethernet (PoE)
• Weatherproofing Rating: IP66
• Impact Resistance Rating: IK10
• Streaming: Dual stream
• Dynamic Range: Digital wide dynamic range (WDR)

Standard Information

• Brand: HUNT ELECTRONICS
• Manufacturer Part Number: hnc324g2-td
