Hubbell Wiring Device-kellems USB15CPDW Usb Receptacle

Product Description

The HUBBELL WIRING DEVICE-KELLEMS USB15CPDW is a tamper-resistant duplex AC receptacle with two integrated USB-A charging ports, rated 15 amps at 125 volts and configured to the NEMA 5-15R standard. It delivers up to 1.5 amps of USB charging power per port and complies with USB PD 3.0 and USB BC1.2 protocols, making it suitable for powering modern devices without a separate adapter block. The white thermoplastic housing is designed for flush mounting in a standard outlet box and is finished in commercial grade to handle higher-use environments. Licensed electricians are the primary installers for this device.

This receptacle is appropriate for commercial and light-commercial installations where both 15-amp AC outlet capacity and USB device charging are required at a single location. Typical applications include office build-outs, hotel guest rooms, healthcare waiting areas, conference rooms, and retail spaces. The integral USB ports eliminate the need for plug-in charging adapters, keeping face plates clear and reducing outlet congestion. Its tamper-resistant shutters make it a code-compliant choice in occupancies where NEC Section 406.9 requirements apply.

Key Features

• Dual USB-A charging ports with 1.5-amp output, compatible with USB PD 3.0 and USB BC1.2
• Tamper-resistant shutters meet NEC Section 406.9 requirements
• NEMA 5-15R duplex AC outlet configuration at 15 amps and 125 volts
• Power indicator light confirms active device status at a glance
• Multiple wiring methods supported: back-wire, side-wire, and terminal screws
• Commercial-grade housing in RTP and thermoplastic construction with screw mounting

Compatibility

Designed as an OEM-style replacement or new-install device for standard single-gang outlet boxes in commercial and residential wiring systems using 15-amp, 125-volt branch circuits.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize the branch circuit at the panel and verify absence of voltage with a non-contact tester before beginning any wiring work. The device supports back-wire, side-wire, and terminal-screw connections — use the method appropriate to the wire gauge and jurisdiction requirements. Do not exceed the 15-amp circuit rating or use this device on circuits above 125 volts.
