Product Description
Hubbell KPA8C is a cable terminal lug designed for use with solid copper conductors. This terminal lug supports conductor sizes from fourteen to eight AWG and is suitable for applications such as connecting cables to equipment pads and terminal blocks, especially in light industrial settings.
- Designed for solid copper conductors
- Supports conductor sizes from fourteen to eight AWG
- Simple installation with one bolt hole and screw
Product Highlights
The KPA8C features a one-piece design that ensures uniform pressure distribution, preventing conductor damage during installation. The tin plating enhances corrosion resistance, making this product a reliable choice in various environments.
Product Information
Standard Information
-
Manufacturer: Hubbell
-
Manufacturer Part Number: KPA8C
Technical Specifications
-
Application: For copper cable, joining to equipment pads or terminal blocks
-
Conductor Size: 14 to 8 AWG
-
Conductor Type: Solid Copper
-
Dimensions: 0.95 in L x 0.72 in H
-
Finish: Tin Plated
-
Material: Copper Alloy
-
Number of Bolt Holes: 1
-
Series: KPA
-
Stud Size: #10
-
Tongue Size: 0.38 in W x 0.06 in THK
-
Tongue Type: Straight
-
Specifications: Slot Robertson, 35 in-lb Installation Torque, (1) Screw
-
Standards/Approvals: ARRA Compliant, Buy American Act Compliant, RoHS Compliant, UL 468A/468B, CSA Certified
