Hubbell Killark OL-45-VG Fiber Conduit Body Gasket

Product Description

The HUBBELL KILLARK OL-45-VG is a fiber conduit body gasket designed to seal Form 35 and Form 85 conduit bodies in 1-1/4 inch and 1-1/2 inch trade sizes. This gasket provides a reliable environmental and hazardous-location seal at the cover interface of the conduit body, maintaining the integrity of the enclosure in classified and general-purpose wiring systems. It is installed by licensed electricians during conduit body assembly or cover replacement on raceway systems where a proper sealing gasket is required by code or specification. The part weighs 0.03 pounds and ships as a single unit.

This gasket is used in electrical raceway installations requiring conduit body sealing in both hazardous and non-hazardous locations. It is applicable to commercial and industrial wiring systems where Form 35 or Form 85 conduit bodies are part of the conduit run. Typical install scenarios include Class I Division 2, Class II, and Class III environments where NEC compliance for conduit body fittings is required. The OL-45-VG meets multiple federal and third-party certifications, making it suitable for use in regulated facility and industrial plant wiring.

Key Features

• Fits 1-1/4 inch and 1-1/2 inch trade size conduit bodies
• Compatible with Form 35 and Form 85 conduit body styles
• Fiber construction suitable for conduit body cover sealing applications
• CSA certified under File LR11852
• EU RoHS compliant
• Meets NEC Article 501.10(b) Class I Division 2, Article 502.10, and Article 503.10 requirements

Compatibility

Designed for use with HUBBELL KILLARK Form 35 Conduit Bodies and Form 85 Conduit Bodies in 1-1/4 inch and 1-1/2 inch trade sizes.

Installation Notes

Installation is performed by a licensed electrician as part of conduit body cover assembly or replacement. De-energize all circuits in the affected raceway before servicing any conduit body fitting. Ensure the gasket seats flat and fully within the cover recess before securing the cover fasteners. Installation must comply with the NEC and any applicable local electrical code requirements for the classified or general-purpose area involved.
