Hubbell HBLDS10 Disconnect Switch 100A Unfused 4X

Product Description

The Hubbell HBLDS10 Disconnect Switch is a non-fusible device designed for effective electrical disconnections. It is rated for 100 amps and is suitable for various industrial applications. The switch features a durable non-metallic enclosure suitable for outdoor use.

• Non-Fusible Type rated for 100 amps
• UL, CSA, and NSF approved for safety
• NEMA 4/4X enclosure providing protection against dust and water

Product Highlights

The HBLDS10 offers a reliable way to control power in electrical installations, ensuring safe operation under demanding conditions.

Product Information

Standard Information

• Manufacturer: Hubbell Wiring Devices-Kellems
• Brand: Hubbell Wiring Devices-Kellems

Technical Specifications

• Voltage Rating: 600 Volt AC
• Current Rating: 100 Amp
• Enclosure Type: NEMA 4/4X/12, IP66
• Size: 7.75 Inch Width x 5.94 Inch Depth x 9.96 Inch Height
• Operator Type: Lockable Rotary Handle
• Circuit Configuration: 3-Phase
• Number of Poles: 3
• Fuse Type: Class J
