HTPG RL6A161ADA Air Defrost Unit Cooler

Product Description

The HTPG RL6A161ADA is an air defrost unit cooler suited for walk-in cooler applications. It utilizes a low-profile design with three fans powered by ECM motors for effective air circulation. The unit functions on a voltage of 115V or 120V at a frequency of sixty Hertz in a single-phase configuration, delivering efficient cooling with a specific BTU rating.

• Air defrost type unit cooler.
• Equipped with three fans and ECM motors.
• Designed for walk-in refrigerator applications.

Product Highlights

This air defrost unit cooler ensures optimal cooling and airflow within walk-in coolers, making it a reliable choice for professional refrigeration needs.

Product Information

Standard Information

• Brand: HTPG
• MPN: RL6A161ADA

Technical Specifications

• Application: Walk-In
• Airflow: 2355 CFM
• BTU Rating: 16,100
• Input Voltage: 115V
• Frequency: 60Hz
• Phase: Single
• Fan Quantity: 3
• Motor Type: ECM
• Defrost Type: Air Defrost
• Style: Low Profile
• Height: 15.5 inches
• Length: 60.125 inches
• Width: 18.125 inches
• Liquid Line Size: 3/8 inches
• Suction Line Size: 5/8 inches
• Rating Point F of 10F TD 25F SST: Capacity (BTUH) 18,800
