Honeywell VU52N1027 Fan Coil Valve Assembly

Product Description

The Honeywell VU52N1027 is a fan coil valve assembly designed for controlling the flow of hot or chilled water in HVAC systems. This two-way valve has a normally open configuration and includes 1/2 inch NPT end connections for iron or steel piping. It is designed to work with VU444 and VU844 actuators. The compact size allows for installation in tight spaces, fitting under most baseboard convector covers when the actuator is attached. It has an operating pressure rating of 300 psi (2,000 kPa, PN20). The valve features an internal ball seal and triple O-ring seal for corrosion and leakage protection.

• Enables two-way, straight-through control of water flow.
• Facilitates installation in confined spaces due to its compact design.
• Allows connection to iron or steel piping via NPT end connections.

Product Highlights

This product is essential for efficient HVAC system operation.

Product Information

Standard Information

• Brand: Honeywell
• MPN: VU52N1027

Technical Specifications

• Manufacturer: Honeywell
• Weight: 4 lbs
• Dimensions (in.): 2 x 2 x 2
• Dimensions (mm): 70 x 70 x 70
• Used With: VU444 Actuator, VU844 Actuator
• Approval: CSA C/US
• Operating Pressure: 300 psi
