HONEYWELL VBN2AGSA1001 Control Ball Valve

Product Description

The Honeywell VBN2AGSA1001 is a 2-way control ball valve specifically designed for regulating the flow of hot or chilled water in HVAC systems. This valve can handle media with up to 50% glycol content. It features a characterized flow design and low torque requirements, making it suitable for a variety of applications. The Cv rating closely aligns with standard globe valves, ensuring performance efficiency.

• Designed for hot or chilled water with up to 50% glycol
• Characterized flow and low-torque design
• Compatible with Honeywell or Kele actuators

Product Highlights

This valve is ideal for use in heating, ventilating, and air conditioning systems, where regulating the flow of liquid is crucial for system performance.

Product Information

Standard Information

• Brand: Honeywell
• MPN: VBN2AGSA1001

Technical Specifications

• Connection: NPT
• Cv: 2.6 CV
• Trim Material: Stainless Steel
• Pattern: 2-way
• Size: 1/2 in
• Control Signal: Floating, Two Position
• Media Compatibility: Hot or chilled water, up to 50% glycol
• Media Temperature Range: -22 to 250F (-30 to 121C)
• Pressure Rating: 360 psig (2482 kPa) @ 250F (121C)
