Honeywell VBF2K21S0X Two-Way Actuated Control Ball Valve

Product Description

The Honeywell VBF2K21S0X is a two-way ball valve that controls hot and chilled water in HVAC systems. Designed for closed-loop systems with up to fifty percent glycol solutions, this valve supports both two-position and modulating operations. The valve has ANSI Class 125 flanged connections for reliable integration.

• Designed for hot and chilled water applications.
• Features ANSI Class IV leakage specification.
• Field-configurable for fail-safe positions.

Product Highlights

This valve is made from durable cast iron, ensuring longevity in various conditions. The removable manual operating handle allows for manual control when needed. The valve accommodates four mounting positions for the actuator, providing versatility during installation.

Product Information

Standard Information

• Brand: Honeywell
• Manufacturer Part Number: VBF2K21S0X

Technical Specifications

• Valve Type: Ball Valve
• Valve Size: 5 inches
• Connection Type: Flanged
• Cv: 240
• Close Off Pressure: 70 psi
• Body Material: Cast Iron
• Stem Material: 316 Stainless Steel
• Flow Characteristics: Equal percentage
• Temperature Range: -22 F to 250 F
• Leakage Specification: ANSI Class IV
• Compatibility: Up to 50% glycol solutions
