Honeywell VBF2J21SRC 2-Way Actuated Control Ball Valve

Product Description

The Honeywell VBF2J21SRC is a 2-way actuated control ball valve for fluid control applications. It has a cast iron body, Teflon seat, and a stainless steel stem. This valve works with hot and chilled water, including up to fifty percent glycol solutions. It includes a removable manual operating handle and can be set for normally open or normally closed positions. An optional NEMA 3R enclosure is available for outdoor placement.

• ANSI Class 125 flanged connections.
• Four actuator mounting positions available.
• Complies with ANSI Class IV leakage standards (0.01% of Cv).

Product Highlights

This valve provides equal percentage and linear flow characteristics with a full port opening.

Product Information

Standard Information

• Brand: Honeywell
• Control Valves Type: Ball Valve

Technical Specifications

• Body Material: Cast Iron
• Size: Four to six inches
• Cv Rating: 254
• Connections: ANSI Class 125 flanged
• Operating Temperature: Minus twenty-two to two hundred fifty degrees Fahrenheit (minus thirty to one hundred twenty-one degrees Celsius)
• Close Off Pressure: Seventy psi
• Service: Hot and chilled water with glycol solutions up to fifty percent
• Flow Characteristic: Equal percentage, linear with full port
• Leakage: ANSI Class IV (0.01% of Cv)
