Resideo V800C1052/U Gas Valve V800 Standing Pilot Step Opening 24 VAC (3/4 x 3/4 Inch NPT)

Brand: RESIDEO
SKU: V800C1052/U
Availability: In Stock

Ships same day if ordered by 12 pm
$769.37
$769.37
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

Resideo V800C1052/U is a standing-pilot gas valve with a step opening design for controlled gas flow in heating and industrial combustion applications. It provides a flow range of 0.9 to 3.5 Inch WC, inlet/outlet connections of 3/4 x 3/4 inch NPT, and is rated to 1/2 psi with an operating temperature range of 32 to 175 degrees Fahrenheit. The valve supports 24 VAC operation and includes pilot gas filtering and flow adjustment.

  • Step opening design for precise flow control; flow range 0.9 to 3.5 Inch WC
  • 3/4 in NPT inlet and outlet connections; pressure rating 1/2 psi (3.5 kPa)
  • Operating temperature 32 to 175 °F; 24 VAC operation; pilot gas filter and flow adjustment

Product Highlights

Standing-pilot, step-opening gas valve for heating and combustion systems with 3/4 x 3/4 in NPT connections, 0.9–3.5 Inch WC flow range, rated to 1/2 psi, and 32–175 °F operating range.

Product Information

Standard Information

  • Brand: RESIDEO
  • Manufacturer Part Number: V800C1052/U
Technical Specifications
Brand
Resideo
MPN
V800C1052/U
Product Type
Gas valve (standing pilot, single stage)
Regulation Type
Step opening
Ignition Type
Standing pilot
Flow Range
0.9 Inch WC to 3.5 Inch WC
Capacity (Max)
425,000 BTU/h
Capacity (Min)
34,000 BTU/h
Input Voltage
24 V AC
Operating Frequency
60 Hz
Inlet Connection
3/4 in NPT
Outlet Connection
3/4 in NPT (straight-through valve body with multi-tapped 1/2 in side outlets, plugged)
Pilot Gas Outlet
Compression fitting for 1/4 in OD tubing
Maximum Operating Pressure
1/2 psi (3.5 kPa)
Operating Temperature Range
32 to 175 °F (0 to 79 °C)
Mounting Orientation
0° to 90° in any direction from upright position of knob, including vertically
Valve Body Pattern
Straight through, multi-tapped with 1/2 in right and left outlets plugged
Dimensions (H x W x L)
4.75 in x 4.06 in x 4.06 in (121 mm x 103 mm x 103 mm)
Approvals
UL Component Recognized MCCZ2.MH5323, P-G-774A; CSA International: 112395
