Honeywell MS8120F1200/U Direct Coupled 175 in-lb Spring Return

Product Description

The Honeywell MS8120F1200/U is a direct coupled actuator designed for commercial building control. This actuator features a torque of 175 lb-in with a spring return mechanism. It operates on 24 VAC and is suitable for two-position control.

• Reversible mounting for clockwise or counterclockwise spring rotation.
• Integral junction box for easy connections.
• Reliable in smoke control systems with UL555S ratings up to 350 F.

Product Highlights

This actuator includes a self-centering shaft adapter and can handle various operating conditions, making it versatile for different HVAC applications.

Product Information

Standard Information

• Brand: Honeywell
• Model Number: MS8120F1200/U

Technical Specifications

• Housing: Aluminum
• Power Consumption: 45 VA
• Operating Conditions: -40 F to 130 F
• Electrical Connection: Teflon-Jacketed Cable
• Dimensions: 10.67 inches high x 3.94 inches wide x 2.95 inches deep
• Weight: 8 lb
• Auxiliary Switch: 2
• Spring Return Timing: 15 seconds
